FeaturesAdjustable Transmitting Power: The transmitter offers four adjustable power levels (PIT, 25mW, 400mW, 800mW, and 2000mW), allowing users to select the appropriate power setting for their needs.IRC Tramp: It supports IRC Tramp , enabling easy changes of power, band, and channel settings for flexible operation and compatibility with betaflight.LED indicators: The transmitter features side LED indicators and an adjustment button, providing intuitive status readings and easy adjustments.Wide Voltage Input: It supports a wide voltage input range of 7-36V DC, accommodating direct input from 2S to 8S batteries, offering flexibility in power supply options.Frequency Range: The transmitter operates across a frequency range of 5362MHz to 5945MHz with 48 adjustable channels, offering extensive options for avoiding interferenceBuilt-in Microphone: The VTX includes a built-in microphone, allowing real-time audio transmission from the drone, which enhances the immersive experience of drone operation.SpecificationsInput Voltage: 7-36V DC;2-8SOutput Voltage: 5V 1A12V Input Current: 185mA@Pitmode, 210mA@25mW, 340mA@400mW, 420mA@800mW, 620mA@2000mWChannels: 48CH (A.B.E.F.R.L;5362MHz-5945MHz)Power: PIT/25/400/800/2000 mWAntenna Connector: MMCXVTX Protocol: IRC-trampMaterial: AluminumDimensions: 37.7*36.1*9.5 mm; 30.5*30.5mm(Hole)Weight: 15.8g (W/ o Antenna)Frequency TablePackage Included1 X 5.8GHz VTX1 X MMCX to SMA Cable1 X 6 Pin 1.0 Harness
