FeaturesWide Frequency Range: With a receiving frequency range of 1120MHz to 1380MHz and 8 adjustable channels, users have flexibility in selecting channels to avoid interference and optimize signal reception.Button Control and LED Indicators: Each red LED corresponds to a different receiving frequency, providing clear visual feedback. Users can easily switch channels by short-pressing the button, with the corresponding LED lighting up to indicate the selected frequency.Power-off Memory Function: The receiver automatically saves the current receiving frequency after each switch. This ensures that when the power is reconnected, the receiver will resume operation at the previously set frequency, eliminating the need for manual adjustment.AV Output: The receiver supports AV output, allowing users to connect it to other screen devices using a video output cable. This enables real-time sharing of the received video feed on external screens, enhancing the FPV experience.Ultra Long Range: With stable and smooth video transmission performance, coupled with compatibility with high-power 1.2GHz VTX (Video Transmitter), this receiver is capable of achieving ultra-long-distance FPV flights. This feature is particularly beneficial for enthusiasts who require extended range capabilities in their FPV setups.SpecificationsReceiving frequency: 8CH (1120MHz to 1380MHz)Input voltage：DC 7-36VCurrent Consumption:（ 280±40）mA @5VButton control and LED indicatorsOn board regulator output: 5V 1ARX Sensitivity: -95dBmVoltage Standing Wave Ratio: 2:1Demodulation System: FM/PLLANT. input impedance: 50Ω, Typ.Video Output impedance: 75Ω, Typ.Audio Subcarrier Frequency: 6.0MHz (AR) 6.5 MHz (AL)RF Connector: SMAWeight: 20g ( w/o antanna)Size: board 44mm (L)*27mm (W)*27mm (H)Frequency TablePackage Included1 X 1.2GHz VRX1 X “Y”Type Antenna1 X Two-channel Video output cable1 X 7P 1.25 single1 head cable
