Feature:Maximum RF power of this transmitter is 2000mW, providing ultra-high power for long-distance video transmission, ensuring strong and stable signals over long distances.The transmitter supports three levels of transmit power (PIT, 25mW, 2000mW), allowing users to select the appropriate power setting based on their specific needs and conditions.This feature enables easy adjustment of power, band and channel settings via IRC-tranp, enhancing flexibility and compatibility with betaflight.The VTX features side LED indicators and adjustment buttons, providing intuitive status readouts and straightforward adjustments for easy management of settings.Full metal casing and independent cooling fan ensure efficient heat dissipation, maintaining stable and smooth transmission even at the maximum power of 2000mW.This VTX operates within an output frequency range of 1060MHz to 1380MHz, providing 9 channels.Ultra-high output power and stable transmission performance enable the transmitter to achieve new long-range recordings, making it ideal for long-range FPV applications.Specification:Input voltage: 7-36V DC; 2-8SOutput voltage: 5V 1A12V Input Current: 235mA@Pitmode, 360mA@25mW, 880mA@2000mW,Channel: 9CH (1060MHz-1380MHz)Power: PIT/25/2000/mWAntenna Connector: MMCXVTX Protocol: IRC-trampMaterial: AluminumDimensions: 37.7*36.1*11 mm; 30.5*30.5mm (Hole)Weight: 16g (W/ o Antenna)Frequency TablePackage Included1 x 1.2GHz VTX1x MMCX to SMA Cable1x 6 Pin 1.0 Harness1x 1.2G Y-Type Dedicated Antenna
